Brand: Siemens
Model: 6ES7155-5AA00-0AC0
Product Name: IM155-5 PN HF Interface Module
Series: SIMATIC ET 200MP
Device Type: High-performance PROFINET IO Interface Module
Communication: PROFINET IO, integrated 2-port RJ45 switch, IRT isochronous, MRP ring redundancy, Shared Device
Max I/O Modules: Up to12 modules without system power supply; up to30 modules with extra PS
Protection Class: IP20
Supply Voltage: DC 24V
Voltage Tolerance: DC19.2V ~ DC28.8V, reverse polarity protection
Dimensions (W×H×D):35mm ×147mm ×129mm
Weight: Approx 140g
Operating Temperature: -25℃ ~ 60℃
Programming Environment: TIA Portal
Product Status: Phase-out
Origin: Germany
Condition: New / Original
Application: S7-1500 distributed remote I/O, motion control, production line real-time control, industrial spare replacement
